SKU: SCH123
Category: Electrical Accessories
Contact Block
Brand:
Schneider
Model: Micro Motion 2700
Partner Number:
LADN11
Description
TeSys D
instantaneous auxiliary contact block for contactors LC1D, LC1F, and control
relays CAD. It provides 1 NO + 1 NC contact (NC mirror certified) rated up to
10A/690V AC, with connection by screw clamp terminals. Clip-on front mounting,
it procures high reliability and durability. Multi-standards certified (IEC,
UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh).
Technical
Data
|
Range |
TeSys TeSys Deca |
|
Product or
component type |
Auxiliary
contact block |
|
Pole contact
composition |
1 NO + 1 NC |
|
Contacts
operation |
Instantaneous |
|
Rated
operational voltage |
690 V AC
25...400 Hz |
|
Conventional free air thermal current |
10 A (at 60 °C) |
|
Rated
insulation voltage |
690 V conforming
to IEC 60947-5-1 600 V conforming
to UL 600 V conforming
to CSA |
