SKU: 326P
Category: Pressure Transmitter
Pressure Transmitter
Brand:
Emerson Rosemount
Model: 326P
Description
The
Rosemount 326P Pressure Transmitter is specifically engineered for pressure and
hydrostatic level applications in the food and beverage industry. A variety of
industry-standard process connections, hygienic certifications (3-A, FDA, EC
1935, etc.), a polished stainless-steel housing, and the ability to withstand
clean-in-place processes enable the transmitter to meet your process
requirements while minimizing contamination risks and assuring product
safety.
Technical Data
|
Interoperability |
Connection accessories sold
separately. See Product Data Sheet for complete list of cables, IO-Link
Masters, etc. |
|
Process Connection |
Adapter sold separately. See
Product Data Sheet for complete list of options. |
|
Accuracy |
0.20% |
|
Communication Protocol |
4-20mA, Switch |
|
Rangedown |
4:1 |
|
Measurement Range |
Up to 360 psig (24,8 bar) |
|
Process Temperature |
Up to 257°F (125°C); 293°F
(145°C) for a maximum of 1 hour |
|
Process Wetted Material |
Ceramic, PTFE, 316L SST
Polished to Ra < 16 µ-in. (0.4 µ-m) |
