SKU: RSM008
Category: Pressure Transmitter
Pressure Transmitter
Brand:
Emerson Rosemount
Model: 3051S
Partner Number: 3051T ( 3051TG4A2B21 )
Description
Confidently measure pressure and level with the Rosemount 3051 In-Line Pressure Transmitter. Engineered for 10-year installed stability and 0.04% of span accuracy, this industry-leading pressure transmitter provides you with the information necessary to run, control and monitor processes. Available with a graphical, back-lit display, Bluetooth® connectivity, and enhanced software capabilities designed to access the data you need faster than ever before.
Technical Data
Rangedown | Up to 150:1 |
Communication Protocol | 4-20 MA HART®, WirelessHART®,
FOUNDATION™ fieldbus, PROFIBUS® PA, 1-5 V Low Power HART® |
Measurement Range | Up to 20000 psig (1378,95 bar)
gage Up to 20000 psia (1378,95 bar)
absolute |
Process Wetted Material | 316L SST, Alloy C-276, Alloy
400, Tantalum, Gold-plated 316L SST, Gold-plated Alloy 400 |
Diagnostics | Basic Diagnostics, Process
Alerts, Loop Integrity Diagnostics, Plugged Impulse Line Diagnostics |
Certifications/Approvals | SIL 2/3 certified to IEC 61508
by an independent 3rd party, NSF, NACE®, hazardous location, see full specs
for complete list of certifications |
Wireless Update Rate | 1 sec. to 60 min., user
selectable |
Wireless Range | Internal antenna (225 m) |
